THE DRAWING MACHINE (2017)

DESIGN BRIEF

• Project: The Drawing Machine
• Designer: Emem Essien
• Material: Wood
• Project Year: 2017

Guarded by DowelsThe purpose of this project is to design and construct a drawing machine to measure and draw a fruit or vegetable. My chosen fruit was a red bell pepper.

Although the construction process was to be done in a design team, the conceptual process (R) was entirely individual.

The final form of the drawing machine is a square-based drawing machine made up of four vertical columns with two horizontal beams joined between each columns, up and down. Gaps are created between each beam to house nuts and bolts which would enable movable measuring sticks with holes of equal spacing for dowels to fit in and measure our individual fruits.
